| Unique Feature |
Superb Productivity: PCIe Gen5 (Graphics, M.2), Dual Channel DDR5, Thunderboltâ„¢ 4 Type-C Ports (40 Gb/s) Rock-Solid Durability: Server-Grade Low-Loss PCB, 18+1+1+1+1 Power Phase, 80A SPS for VCore+GT+SA with Enlarged Heatsink Armor, Memory OC Shield, Flexible Integrated I/O Shield, 20K Long-lasting Black Caps (High-quality capacitors) Ultrafast Gaming: Killer 2.5G LAN, 802.11be Wi-Fi 7 Module, ASRock Lightning Gaming Ports EZ Update: BIOS Flashback Button, ASRock Auto Driver Installer EZ Troubleshooter: ASRock Post Status Checker
|
| CPU |
Supports Intel® Core™ Ultra Processors (Series 2) (LGA1851RL-ILM), Intel® Hybrid Technology, Intel® Turbo Boost Max 3.0, Intel® Thermal Velocity Boost (TVB), Adaptive Boost Technology (ABT), Integrated NPU for AI acceleration |
| Chipset |
Intel® Z890 |
| Memory |
Dual Channel DDR5, 4 DIMM Slots, Up to 9466MHz+(OC), Max Capacity 256GB, Supports XMP 3.0x |
| BIOS |
256Mb AMI UEFI Legal BIOS with GUI support |
| Graphics |
Intel® Xe LPG Graphics Architecture, 1 x HDMI 2.1 (4K@120Hz), 2 x Thunderbolt™ 4 (8K@60Hz / 5K@120Hz) |
| Audio |
Realtek ALC1220 Codec, 7.1 CH HD Audio, Nahimic Audio, Impedance Sensing |
| LAN |
Killer 2.5G LAN (E3100G), Supports Killer LAN Software |
| Wireless LAN |
802.11be Wi-Fi 7, Bluetooth 5.4, Supports 2.4/5/6GHz bands, 320MHz channel bandwidth |
| Slots |
PCIe 5.0 x16 (CPU), PCIe 4.0 x16, PCIe 4.0 x1 (Chipset), M.2 Key E (Wi-Fi/BT) |
| Storage |
5 x M.2 Sockets (Gen5x4, Gen4x4), 4 x SATA3 6.0 Gb/s Connectors, Supports RAID 0/1/5/10 |
| USB Ports |
Thunderboltâ„¢ 4 Type-C, USB 3.2 Gen2x2 Type-C, USB 3.2 Gen2 Type-A, USB 3.2 Gen1, USB 2.0 |
| Connectors |
Thermistor Cable, RGB LED Header, Addressable LED Headers, CPU/Chassis/AIO/Water Pump Fan Connectors, ATX Power Connectors, Front Panel Audio Connector |
| Rear Panel I/O |
HDMI Port, Optical SPDIF, Thunderboltâ„¢ 4 Ports, USB 3.2 Gen2/Gen1, USB 2.0, RJ-45 LAN, BIOS Flashback Button, Gold Audio Jacks |
| Software & UEFI |
ASRock Phantom Gaming Tuning, Killer Control Center, ASRock Polychrome SYNC, EZ Mode UEFI |
| Accessories |
2 x SATA Data Cables, Wi-Fi Antenna, ARGB Splitter, Thermistor Cable |
| Form Factor |
ATX (12.0 x 9.6 inches), 2oz Copper PCB |
| OS Support |
Windows® 10 64-bit / 11 64-bit |
| Certifications |
FCC, CE, ErP/EuP ready |
